BWU1488 – BWU2545 – BWU2544 – Cổng giao tiếp ASi – Bihl-Wiedemann – STC Vietnam
Hãng sản xuất: Bihl-Wiedemann Vietnam
Xuất sứ: Germany
Nhà cung cấp: STC Vietnam
Với cổng giao tiếp ASi từ Bihl + Wiedemann, bạn có thể truyền dữ liệu kỹ thuật số và dữ liệu analog đã được đọc từ xa thông qua các slave ASi đến bộ điều khiển máy chủ và đặt tín hiệu đầu ra từ bộ điều khiển máy chủ tới bộ truyền động qua hệ thống BUS tương ứng.
Các cổng giao tiếp của Bihl+Wiedemann đều theo chuẩn ASi-3 resp. ASi-5 và do đó đảm bảo trao đổi dữ liệu tối ưu. Chúng rất đơn giản và nhanh chóng để cài đặt và nghiệm thu. Người dùng được hưởng lợi từ nhiều chức năng chẩn đoán được triển khai tiêu chuẩn như phát hiện địa chỉ trùng lặp, lỗi nối đất và giám sát EMC cũng như chức năng PLC tùy chọn.
Double Master trong một cổng là một cách tiếp cận đặc biệt tiết kiệm chi phí. Điều này cho phép hai mạch ASi được điều khiển bởi một cổng. Phiên bản “1 Gateway, 1 cấp nguồn cho 2 mạch ASi” cũng chỉ yêu cầu một nguồn cấp cho cả hai mạch ASi.
Danh mục chọn code của cổng giao tiếp ASi Bihl-Wiedemann: BWU1488 – BWU2545 – BWU2544
| Type | Fieldbus interface 2 | Number of ASi networks, number of ASi Master 3 | 1 power supply, 1 gateway for 2 ASi networks, inexpensive power supplies 4 | Diagnostic and configuration interface 5 | Recognition of duplicate ASi addresses 6 | ASi fault detector 7 | Programming in C 8 | Article No. |
| 24 Volt ASi-5/ASi-3 Gateway | PROFINET, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus | yes | yes | no | BWU3847 |
| 24 Volt ASi-5/ASi-3 Gateway | EtherNet/IP + ModbusTCP, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus | yes | yes | no | BWU3849 |
| 24 Volt ASi-5/ASi-3 Gateway | EtherCAT, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | no | BWU3854 |
| 24 Volt ASi Gateway | POWERLINK, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | no | BWU4016 |
| 24 Volt ASi Gateway | PROFIBUS | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | – | yes | yes | no | BWU3053 |
| 24 Volt ASi Gateway | POWERLINK | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | – | yes | yes | no | BWU3312 |
| 24 Volt ASi Gateway | CC-Link | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | – | yes | yes | no | BWU3051 |
| PROFIBUS ASi | PROFIBUS | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU2546 |
| PROFIBUS ASi | PROFIBUS | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | Ethernet diagnostic | yes | yes | optional | BWU2545 |
| PROFIBUS ASi | PROFIBUS | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | Ethernet diagnostic | yes | yes | optional |
BWU2544 |
| 24 Volt ASi Gateway | PROFIBUS | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | – | yes | yes | no | BWU3053 |
| PROFIBUS ASi Basic | PROFIBUS | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | – | no | yes | no | BWU1746 |
| PROFINET ASi-5/ASi-3 gateway | PROFINET, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3852 |
| PROFINET ASi-5/ASi-3 gateway | PROFINET, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 8 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3848 |
| PROFINET ASi gateway | PROFINET, OPC UA | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | Ethernet fieldbus | yes | yes | optional | BWU3844 |
| PROFINET ASi gateway | PROFINET, OPC UA | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet fieldbus | yes | yes | optional | BWU3759 |
| PROFINET ASi gateway | PROFINET, OPC UA | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | Ethernet fieldbus | yes | yes | optional | BWU3758 |
| PROFINET ASi gateway | PROFINET | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3431 |
| Starter Kits | PROFINET, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus | yes | yes | – | BW4211 |
| EtherNet/IP + Modbus TCP ASi-5/ASi-3 gateway | EtherNet/IP + ModbusTCP, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3851 |
| EtherNet/IP + Modbus TCP ASi-5/ASi-3 gateway | EtherNet/IP + ModbusTCP, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 8 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU4019 |
| EtherNet/IP + ModbusTCP ASi gateway | EtherNet/IP + ModbusTCP, OPC UA | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet fieldbus | yes | yes | optional |
BWU3736 |
| EtherNet/IP + ModbusTCP ASi gateway | EtherNet/IP + ModbusTCP, OPC UA | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | Ethernet fieldbus | yes | yes | optional | BWU3735 |
| EtherNet/IP + ModbusTCP ASi gateway | EtherNet/IP + ModbusTCP, OPC UA | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | Ethernet fieldbus | yes | yes | optional | BWU3734 |
| Starter Kits | EtherNet/IP + ModbusTCP, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus | yes | yes | – | BW4229 |
| BACnet/IP ASi gateway | BACnet/IP | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3356 |
| DeviceNet ASi gateway | DeviceNet | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | RS 232 | yes | yes | no | BWU1820 |
| DeviceNet ASi gateway | DeviceNet | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | RS 232 | yes | yes | no | BWU1819 |
| DeviceNet ASi gateway | DeviceNet | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | RS 232 | yes | yes | no | BWU1818 |
| ControlLogix ASi gateway | ControlLogix | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network | RS 232 | no | no | no |
BWU1488 |
| ControlLogix ASi gateway | complete set ControlLogix | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network | RS 232 | no | no | no | BW1611 |
| Compact- / MicroLogix ASi gateway | CompactLogix, MicroLogix1500 | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | RS 232 | no | no | no | BWU1416 |
| Compact- / MicroLogix ASi gateway | complete set CompactLogix, MicroLogix1500 | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | RS 232 | no | no | no | BW1610 |
| EtherCAT ASi | EtherCAT | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | no | BWU2720 |
| EtherCAT ASi | EtherCAT | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | RS 232 | yes | yes | no |
BWU2163 |
| EtherCAT ASi | EtherCAT | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | RS 232 | yes | yes | no | BWU2162 |
| 24 Volt ASi-5/ASi-3 Gateway | EtherCAT, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | no | BWU3854 |
| CC-Link ASi | 1 ASi network, 1 ASi Master | CC-Link | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | no | yes | no | BWU2611 |
| 24 Volt ASi Gateway | 1 ASi network, 1 ASi Master | CC-Link | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | yes | yes | no | BWU3051 |
| RS 485 Modbus ASi | Modbus/RTU; RS 485 | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | RS 232 | yes | yes | no | BWU1643 |
| RS 485 Modbus ASi | Modbus/RTU; RS 485 | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | RS 232 | yes | yes | no | BWU1642 |
| RS 485 Modbus ASi | Modbus/RTU; RS 485 | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | RS 232 | yes | yes | no | BWU1641 |
| RS 232 ASi | RS 232 | 1 ASi network, 1 ASi Master | no, max. 8 A/ASi network | no | yes | no | BWU1955 | |
| PROFIsafe, PROFIBUS | PROFIBUS | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU2819 |
| Safety, PROFIBUS | PROFIBUS | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional |
BWU2822 |
| Safety, PROFIBUS | PROFIBUS | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU2793 |
| PROFIsafe, PROFINET, ASi-5 / ASi-3 | PROFINET, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3674 |
| PROFIsafe, PROFINET, ASi-5 / ASi-3 | PROFINET, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional |
BWU3862 |
| Safety, PROFINET ASi-5/ASi-3 | PROFINET, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU4000 |
| Safety, PROFINET ASi-5/ASi-3 | PROFINET, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3863 |
| Safety, PROFINET ASi-5/ASi-3 | PROFINET, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3998 |
| Safety, PROFINET | PROFINET | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU2798 |
| Safety, Sercos ASi-5/ASi-3 | Sercos, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU3861 |
| Safety, Sercos ASi-5/ASi-3 | Sercos, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU3860 |
| Safety, Sercos ASi-5/ASi-3 | Sercos, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU3845 |
| Safety, EtherNet/IP + Modbus TCP, ASi-5 / ASi-3 | EtherNet/IP + ModbusTCP, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3857 |
| Safety, EtherNet/IP + Modbus TCP, ASi-5 / ASi-3 | EtherNet/IP + ModbusTCP, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional |
BWU3825 |
| Safety, EtherNet/IP + Modbus TCP, ASi-5 / ASi-3 | EtherNet/IP + ModbusTCP, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3866 |
| Safety, EtherNet/IP + ModbusTCP | EtherNet/IP + ModbusTCP, OPC UA | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3693 |
| Safety, EtherNet/IP + ModbusTCP | EtherNet/IP + ModbusTCP | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional |
BWU3543 |
| Safety, EtherNet/IP + ModbusTCP | EtherNet/IP + ModbusTCP | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3544 |
| Safety, EtherNet/IP + ModbusTCP | EtherNet/IP + ModbusTCP | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU3542 |
| BACnet/IP – Gateway with integrated Safety Monitor | BACnet/IP | 2 ASi networks, 2 ASi Masters | no, max. 8 A/ASi network, redundant supply | Ethernet fieldbus + Ethernet diagnostic | yes | yes | optional | BWU4001 |
| DeviceNet Gateway with integrated Safety Monitor | DeviceNet | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional |
BWU2972 |
| EtherCAT ASi-5/ASi-3 Gateway with integrated Safety Monitor | EtherCAT, OPC UA | 2 ASi networks, 2 ASi-5/ASi-3 Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU3858 |
| EtherCAT ASi-5/ASi-3 Gateway with integrated Safety Monitor | EtherCAT, OPC UA | 1 ASi network, 1 ASi-5/ASi-3 Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU3991 |
| EtherCAT Gateway with integrated Safety Monitor | EtherCAT | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU2944 |
| EtherCAT Gateway with integrated Safety Monitor | EtherCAT | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU3509 |
| EtherCAT Gateway with integrated Safety Monitor | EtherCAT | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU2797 |
| POWERLINK Gateway with integrated Safety Monitor | POWERLINK | 2 ASi networks, 2 ASi Masters | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional |
BWU3176 |
| POWERLINK Gateway with integrated Safety Monitor | POWERLINK | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU3177 |
| CANopen Gateway with integrated Safety Monitor | CANopen | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU2804 |
| CC-Link Gateway with integrated Safety Monitor | CC-Link | 1 ASi network, 1 ASi Master | yes, max. 4 A/ASi network | Ethernet diagnostic | yes | yes | optional | BWU2833 |
======================================================
Xem thêm BWU1488 – BWU2545 – BWU2544 – Cổng giao tiếp ASi – Bihl-Wiedemann
Xem thêm bài viết đại lý Bihl-Wiedemann tại Vietnam – STC Vietnam
Xem thêm các sản phẩm Bihl-Wiedemann Vietnam
======================================================
STC là đại lý chính hãng Apiste tại Việt Nam cung cấp sản phẩm BWU1488 – BWU2545 – BWU2544 – Cổng giao tiếp ASi – Bihl-Wiedemann. Một số mã chúng tôi có sẵn kho. Vui lòng liên hệ ngay để nhận được giá tốt nhất.
Sẵn giá – Báo ngay – Bảo hành 12 tháng – Tư vấn, lắp đặt 24/7
